Product Characteristics
Model No. |
|
Module Effeciency |
18 % |
Product Warranty |
10 Years |
Power Warranty |
12 Years of 90% Output Power, 25 Years of 80.2% Output Power |
Electrical Data at STC |
|
Maximum Power (Pmax) |
|
Voltage at Maximum Power (Vmpp) |
|
Current at Maximum Power (Impp) |
|
Open Circuit Voltage (Voc) |
|
Short Circuit Current (Isc) |
|
Panel Efficiency |
|
Power Tolerance (Positive) |
|
|
Standard Test Conditions (STC): air mass AM 1.5, irradiance 1000W/m2, cell temperature 25°C |
Panel Dimension (H/W/D) |
1670 × 998 × 6 mm , 1674 × 1002 × 6 mm with edge banding |
Weight |
23.5 kg |
Nominal Operating Cell Temperature (NOCT): 800W/m2, AM 1.5, windspeed 1m/s,ambient temperature 20°C Thermal Ratings
Operating Temperature Range-40~85 °C Temperature Coefficient of Pmax-0.39 %/°C Temperature Coefficient of Voc-0.29 %/°CTemperature Coefficient of Isc0.048 %/°C Maximum Ratings
Maximum System Voltage 1500V DC (IEC) 1000V DC (UL)
MAX Series Fuse Rating 20 A
Cell Type Monocrystalline P-type 156.75 × 156.75 mm (6 inches)
Cell Number 60
25% Albedo: Maximum Power (Pmax) Module Efficiency STC (%) 375 Watt 22.5 %
